Vacon Page 13
Pump control with autochange
Group 3, Output and supervision parameters
Code Parameter Range Step Default Custom Description Page
3. 1 Analogue output function 0—15 1 1 0 = Not used
Scale 100% 26
1 = O/P frequency
(0—f
max
)
2 = Motor speed (0—max. speed)
3 = O/P current (0—2.0 x I
nCX
)
4 = Motor torque (0—2 x T
nCX
)
5 = Motor power (0—2 x P
nCX
)
6 = Motor voltage (0—100% xU
nM
)
7 = DC-link volt. (0—1000 V)
8—10 = Not in use
11 = PI-controller reference value
12 = PI-controller actual value 1
13 = PI-controller actual value 2
14 = PI-controller error value
15 = PI-controller output
3. 2
Analogue output filter time 0.01—10 s 0.01 1.00 26
3. 3
Analogue output inversion 0—1 1 0 0 = Not inverted 26
1 = Inverted
3. 4
Analogue output minimum 0—1 1 0 0 = 0 mA 26
1 = 4 mA
3. 5 Analogue output scale 10—1000% 1% 100% 26
3. 6 Digital output function 0—30 1 3 0 = Not used 27
1 = Ready
2 = Run
3 = Fault
4 = Fault inverted
5 = Vacon overheat warning
6 = External fault or warning
7 = Reference fault or warning
8 = Warning
9 = Reversed
10 = Jogging speed selected
11 = At speed
12 = Motor regulator activated
13 = Output freq. limit superv. 1
14 = Output freq. limit superv. 2
15 = Torque limit supervision
16 = Reference limit supervision
17 = External brake control
18 = Control from I/O terminals
19 = Frequency converter
temperature limit supervision
20 =
Unrequested rotation direction
21 = External brake control inverted
22 = Analogue input supervision
22—26 = Not in use
27 =Autochange 3 control
28 = Auxiliary drive 1 start
29 = Auxiliary drive 2 start
30 = Auxiliary drive 3 start
3. 7 Relay output 1 function
0—31 1 26 0-25 = As parameter 3. 6 27
26 = Autochange 1 control
27 = Autochange 4 control
28-30 = As parameter 3. 6
31 = Aux. drive 4 start
3. 8 Relay output 2 function 0—30 1 26 0-25 = As parameter 3. 6 28
26 = Autochange 2 control
27 = Autochange 5 control
28-30 = As parameter 3. 6
Note! = Parameter value can be changed only when the frequency converter is stopped. (Continues)
