Pump and fan control with autochange
Code Parameter Range Step Default Custom Description Page
3. 9 Output freq. limit 1 0—2 1 0 0 = No 28
supervision function 1 = Low limit
2 = High limit
3. 10 Output freq. limit 1 0—f
max
0.1 Hz 0 Hz 28
supervision value (par. 1. 2)
3. 11 Output freq. limit 2 0—2 1 0 0 = No 28
supervision function 1 = Low limit
2 = High limit
3. 12 Output freq. limit 2 0—f
max
0.1 Hz 0 Hz 28
supervision value (par. 1. 2)
3. 13 Torque limit 0—2 1 0 0 = No 28
supervision function 1 = Low limit
2 = High limit
3. 14 Torque limit 0—200% x 1% 100% 28
supervision value T
nCX
3. 15 Active reference limit 0—2 1 0 0 = No 29
supervision function 1 = Low limit
2 = High limit
3. 16 Active reference limit 0—f
max
0.1 Hz 0 Hz 29
supervision value (par. 1. 2)
3. 17 External brake off-delay 0—100.0 s 1 0.5 s 29
3. 18 External brake on-delay 0—100.0 s 1 0.5 s 29
3. 19 Frequency converter 0—2 1 0 0 = No 30
temperature limit 1 = Low limit
supervision function 2 = High limit
3. 20 Frequency converter -10—+75°C 1 +40°C30
temperature limit
3. 21 I/O-expander board (opt.) 0—7 1 3 See parameter 3. 130
analogue output content
3. 22 I/O-expander board (opt.) 0.01—10 s 0.01 1.00 See parameter 3. 230
analogue output filter time
3. 23 I/O-expander board (opt.) 0—1 1 0 See parameter 3. 330
analogue output inversion
3. 24 I/O-expander board (opt.) 0—1 1 0 See parameter 3. 430
analogue output minimum
3. 25 I/O-expander board (opt.) 10—1000% 1 100% See parameter 3. 530
analogue output scale
3. 26 Analog output bias 0—100,00% 0,01% 0,00% 30
(basic control board)
3. 27 I/O-expander board (opt.) 0—100,00% 0,01% 0,00% 30
analogue output bias
3. 28 Analogue input 0—210 0 = U
in
signal (control board) 30
supervision input 1 = I
in
signal (control board)
2 = Option board Ain1-signal
3 = Option board Ain2-signal
3. 29 Analogue input 0—2 1 0 0 = No 30
supervision function 1 = Low limit
2 = High limit
3. 30 Analogue input 0—100% 0.1 % 0,0 % 30
supervision value
