vacuubrand BVC basic - Default Chapter; Table of Contents

Content
3
CONTENT
1 Introduction 5
1.1Userinformation................................5
1.2Aboutthisdocument.............................6
1.2.1Symbolsandicons............................6
1.2.2Displayconventions...........................7
2 Safety instructions 8
2.1Targetgroups ..................................8
2.2Safetyprecautions..............................8
2.2.1Personalresponsibility.........................9
2.2.2Eliminatesourcesofdanger.....................9
2.3Environmentalprotection........................10
3 Notes concerning repair 11
3.1Typicallifetime................................11
3.2Priortomaintenanceandrepair ...................12
3.3Aftermaintenanceandrepair .....................12
3.4Replacingdiaphragmsandvalves.................13
4 Replacing the main switch 14
5 Replacing the circuit board 19
6 Replacing the motor capacitor 25
7 Exploded drawing 33
8 Spare parts 40
9 Circuit diagram 44
10 Service 45
10.1Termsofservice..............................45
10.2Servicerequests ..............................46
10.3Return ......................................46
11 Health and safety clearance form 47
