ecoTEC plus 937 installation and maintenance manual8
241
20
642
720
883
100100
440
35
35
175
6
4
3
2
1
5
130
180
198
12345
7
8
Fig. 2.2 Dimensions shift load storage tank
Key
1 Heating return pipe, Ø 22 mm
2 Cold water connection, Ø 15 mm
3 Gas connection Ø 22 mm
4 Hot water connection, Ø 15 mm
5 Heating flow pipe, Ø 22 mm
6 Hanging bracket
7 Shift load storage tank pressure relief connection (flexible hose
supplied)
8 Cover
2 Unit description, data and dimensions
