Appendix
0020237615_01 multiMATIC Operating instructions 23
Appendix
A Overview of the end user and display functions
Note
The functions and operating modes listed are not available for all system configurations.
A.1 Operating modes
Operating mode Setting Default setting
Operating mode
Heating off, Auto, Day, Set-back Auto
Cooling off, Auto, Day Auto
Ventilation Auto, Day, Set-back Auto
Domestic hot water off, Auto, Day Auto
Advanced functions
Manual cooling active –
1 day at home active –
1 day away from home active –
Ventilation boost active –
Party function active –
Cylinder boost active –
System OFF active active –
A.2 End user level
The description of the functions for ZONE1 also applies for all available zones.
Setting level Values Unit Increment, select Default setting
Min. Max.
Information → System status →
System ----
Fault status Current value No fault, Fault list
Green IQ Off, On On
Water pressure Current value bar
System status Current value Standby, Heat. mode, Cool-
ing, DHW
Burner Current value On, off
Collector temp. Current value ℃
Solar yield Current value kWh
Reset solar yield Yes, No No
Environmental yield Current value kWh
Curr. room air hum. Current value %
Current dew point Current value ℃
triVAI Current value
Battery status Current value Critical, OK
Signal strength Current value 1
ZONE1 ----
Day temp. heating 5 30 ℃ 0.5 20
Day temp. cooling 15 30 ℃ 0.5 24
Set-back temp. heat. 5 30 ℃ 0.5 15
Room temperature Current value ℃
Ventilation ----
