Notes on the documentation 2
0020237615_01 multiMATIC Operating instructions 5
2 Notes on the documentation
2.1 Observing other applicable documents
▶ You must observe all operating instructions enclosed with
the system components.
2.2 Storing documents
▶ Keep this manual and all other applicable documents
safe for future use.
2.3 Validity of the instructions
These instructions apply only to:
VRC 700f/4 – article number
Austria
0020218359
Belgium
0020231557
Germany
0020218359
Switzerland
0020231557
2.4 Nomenclature
The following terms are used for simplification:
– Control: This refers to the VRC 700f/4 radio control.
– Remote control: This refers to the VR 91f remote control.
– Outdoor temperature sensor: This refers to the wireless
outdoor temperature sensor.
2.5 Function availability
Note
The functions described in these operating in-
structions are not available for all system configur-
ations.
The controller only shows the functions that are available in
the system configuration you have installed.
3 Product description
3.1 Design of the product
3.1.1 Radio receiver unit
4
3
1
2
1 Wall-mounting base
2 Diagnostics socket
3 LED status display
4 Teach-in button
3.1.2 Radio controller
2
1
3
2
5
6
4
1 Display
2 Selection button
3 Diagnostics socket
4 Battery compartment
5 Wall-mounting base
cover
6 Rotary knob
