3.6 Preventing malfunctions
▶ Ensure that air can circulate freely around the controller,
and that the controller is not covered by furniture, cur-
tains or other objects.
▶ Ensure that all radiator valves in the room where the con-
troller is fitted are fully open.
3.7 Identification plate
The data plate is located on the rear of the control under-
neath the unit mounting bracket.
The identification plate contains the following information:
Information on the identific-
ation plate
Meaning
Serial number for identification; 7th to
16th digits = product article
number
multiMATIC Product designation
V Operating voltage
mA Current consumption
Read the instructions
LR06 Battery type designation
T60 Max. permitted environmental
temperature: 0 to 60 °C
3.8 Serial number
You can call up the serial number to the display under Menu
→ Information → Serial number. The 10-digit article number
is located in the second line.
3.9 CE marking
The CE mark shows that the products comply with the basic
requirements of the applicable guidelines as stated on the
data plate.
The manufacturer hereby declares that the type of radio
equipment that is described in these instructions complies
with Directive 2014/53/EU. The complete text of the EU de-
claration of conformity can be viewed at the manufacturer's
site.
4 Operation
4.1 Operating structure
4.1.1 Adjustment and display levels
The product has two adjustment and display levels.
The end user level contains information and setting options
that you require as the end user.
The installer level is reserved for the competent person. It is
protected by a code. Only competent persons may change
any settings in the installer level.
End user level (→ Page 23)
4.1.2 Menu structure design
The menu structure consists of several selection levels and a
setting level.
You can always use the selection button Menu to access
selection level 1 from the basic display.
You can use the selection button Op. mode to directly ac-
cess the setting level Operating mode.
The lowest level is always the setting level.
4.1.3 Selection level
Menu
Information
Desired temperatures
Timer programmes
Back
Select
1
4
3
2
1 Scroll bar
2 Current functions of the
selection buttons
3 Selection level list
entries
4 Current function or
selection level
The scroll bar (1) only appears if there are more list entries
than can be shown at once on the display.
4.1.4 Setting level
Zone 1
Set-back temp. heat.Set-back temp. heat.
Day temp. coolingDay temp. cooling
Day temp. heatingDay temp. heating
Back
Change
20.0 °C20.0 °C
26.0 °C26.0 °C
15.0 °C15.0 °C
21
3
5
4
1 Current selection
2 Current selection level
3 Values
4 Current functions of the
selection buttons
5 Setting level
In the setting level, you can select the values you want to
read or change.
