10.2 Technical data for VIH RW 300
Units VIH RW 300
Nominal cylinder capacity l 300
Actual cylinder capacity l 285
Maximum operating pressure – cylinder bar 10
Maximum operating pressure - heating bar 10
Max. hot water temperature °C 85
Maximum hot water forward flow tem-
perature
°C 110
Standby energy loss kWh/d 1.8
Heating heat exchanger:
Heating area of the heat exchanger m
2
2.9
Heating water capacity of the heat ex-
changer
l 17.5
Pressure loss in the heat exchanger at
max. hot water demand mbar 124
Heating medium flow l/h 2000
Initial hot water output at 10/45 °C and a
cylinder temperature of 60 °C l/10min 410
Continuous hot water output at 10/45 °C
and a heating water temperature of
60/50 °C kW 14
Continuous hot water output at 10/45 °C
and a heating water temperature of
60/50 °C l/h 345
Output characteristic figure N
L
–
Connections
Cold water and hot water connection Thread R1
Secondary return connection Thread R
3
/
4
Flow and return connections Thread R1
Cylinder dimensions:
Width with casing mm 660
Depth with casing mm 725
Height mm 1775
Outer diameter of tank without insula-
tion mm 500
Weight (incl. packaging and insulation) kg 155
Weight when filled and ready for
operation
kg 440
Table 10.2 Technical data for VIH RW 300
10 Technical data

Vaillant uniSTOR Specifications

General

Maximum Operating Pressure	10 bar
Capacity	120L, 150L, 200L, 300L
Insulation	High-density foam insulation
Thermal Insulation	High-density foam insulation
Weight	50 kg
Dimensions (Height x Diameter)	Varies by model
