Operating instructions for electric domestic hot water cylinders VEN 5/6 U and O (plus) 0020129648_02 23
Technical data 15
15 Technical data
Unit designation Units
VEN 5/6 U
plus
VEN 5/6 O
plus
Article number 001012791 0010012792
Version Electric domestic hot water cylinder, open-vented system with mains cable
For supplying one draw-off point 1)
Design for undercounter installation for overcounter installation
Capacity l 5 5
Dimensions 2)
Height 2) mm 418 418
width mm 240 240
depth mm 218 218
Weight when filled with water kg 8 8
Performance characteristics
Operating mode Single-circuit Single-circuit
Blended water volume from 40 °C 3) l 9.5 9.5
Standby energy consumption KWh/24 hrs 0.24 0.24
Max. operating pressure MPa (bar) 0 0
Configuration
Inner tank Plastic Plastic
Temperature can be selected up to
approximately
°C 85 85
Economy mode at approximately °C 60 60
Temperature limiting possible to 4) °C 40/60 40/60
Electrical supply 1/N/PE 1/N/PE
Measuring voltage V/Hz 230/50 230/50
Rated output kW 2 2
Safety Radio-shielded, non-interacting with the mains supply
type of protection IP 24 D= splash-proof
Recommended outlet valve/fitting Available from unit supplier 5)
Tab.15.1 Technical data
1) Open-vented system (non-pressurised)
2) Including water connection (without valve/fitting)
3) The blended water volume for a service temperature of 40 °C
results from adding cold water to the 65 °C cylinder water with
the unit ready to operate
4) Water temperature of approximately 40 °C, e.g. for bathroom use;
water temperature of approximately 60 °C, e.g. for kitchen use
5) See price list
