A.14 aroTHERM with system separation, hot water generation using a gas-fired condensing boiler
(eBUS)
Cylinder Equipment Heating cir-
cuits
Setting for
System
diagram
VR 70 VR 71
Monovalent domestic hot water
cylinder for heat pump
Cylinder charging using the condensing
unit
Heat exchanger module for heat pump
1 direct 10
Monovalent domestic hot water
cylinder for heat pump
Cylinder charging using the condensing
unit
Heat exchanger module for heat pump
1 direct
1 mixed
10 1
Monovalent domestic hot water
cylinder for heat pump
Cylinder charging using the condensing
unit
Heat exchanger module for heat pump
2 mixed 10 5
Monovalent domestic hot water
cylinder for heat pump
Cylinder charging using the condensing
unit
Heat exchanger module for heat pump
2 mixed 10 3
A.15 aroTHERM or flexoTHERM, hot water generation using a heat pump and gas-fired condensing
boiler (eBUS)
Cylinder Equipment Heating cir-
cuits
Setting for
System
diagram
VR 70 VR 71
Monovalent domestic hot water
cylinder for heat pump
Cylinder charging using a condensing unit
and heat pump
Hydraulic module
1 direct
1 mixed
12 1
Monovalent domestic hot water
cylinder for heat pump
Buffer cylinder
Cylinder charging using a condensing unit
and heat pump
Buffer cylinder for heating circuits only
2 mixed 12 5
Monovalent domestic hot water
cylinder for heat pump
Buffer cylinder
Cylinder charging using a condensing unit
and heat pump
Buffer cylinder for heating circuits only
3 mixed 12 3
A.16 aroTHERM with system separation, hot water generation using a heat pump and gas-fired con-
densing boiler (eBUS)
Cylinder Equipment Heating cir-
cuits
Setting for
System
diagram
VR 70 VR 71
Monovalent domestic hot water
cylinder for heat pump
Cylinder charging using a condensing unit
and heat pump
Hydraulic module
Heat exchanger module
1 direct
1 mixed
13 1
allSTOR buffer cylinder Buffer cylinder charging using a condens-
ing unit and heat pump
Hydraulic module
Heat exchanger module
2 mixed 13 5
Monovalent domestic hot water
cylinder for heat pump
Cylinder charging using a condensing unit
and heat pump
Hydraulic module
Heat exchanger module
3 mixed 13 3
