• Screw terminal wire size: 0.5 ... 2.5 mm
2
• Flat head screwdriver: 0.6×3.5 mm
Make sure that you prepare or connect only de-energized wires.WARNING!
Do not connect any wires to unused terminals (for example, if you
are using only analog outputs, do not connect wires to the RS-485 terminals).
Connecting unnecessary wires can increase the power consumption and cause
heating.
CAUTION!
Chapter 3 – Installation
17
