Data Link Layer Options BACnet Internet Protocol (IP) (Annex J)
BACnet IP (Annex J), Foreign Device
ISO 88023, Ethernet (Clause 7)
ANSI/ATA 878.1, 2.5 MB ARCNET® network
(Clause 8)
ANSI/ATA 878.1, RS485 ARCNET network
(Clause 8), baud rates: _________
Master-Slave/Token-Passing (MS/TP) master
(Clause 9), baud rates: 9600, 19200, 38400,
57600, 76800, 115200
MS/TP slave (Clause 9), baud rates:
_________
Point-To-Point, EIA 232 (Clause 10), baud
rates: _________
Point-To-Point, modem (Clause 10), baud
rates: _________
LonTalkâ protocol (Clause 11), medium:
_________
Other: _________
Device Address Binding: Is static device binding supported? (required for
two-way communication between MS/TP slaves
and other devices)
Yes
No
Networking Options Router, Clause 6: _________
Annex H, BACnet Tunneling Router over IP
BACnet/IP Broadcast Management Device
(BBMD)
Does the BBMD support registrations by Foreign
Devices?
Yes
No
HMD65 User Guide M212243EN-A
58
