Vaisala HPP272 - Dimensions; Figure 14 HPP272 Dimensions; Table 7 Mechanical Specifications; Table 8 Operating Environment

Table 7 Mechanical Specifications
Property Description/Value
Weight 130 g
IP rating IP65
Connector M12/5 male
Materials
Probe body AISI316L stainless steel
Filter cap Porous PTFE
Temperature probe AISI316L stainless steel
Temperature probe cable PTFE
Table 8 Operating Environment
Property Description/Value
Operating temperature +0 ... +70 °C (+32 ... +158 °F)
Storage temperature -20 ... +70 °C (-4 ... +158 °F)
Ambient pressure Normal atmospheric pressure
EMC compliance EN61326-1, Controlled Environment
10.1 Dimensions
118.3
44
Ø=18.5
69.8, Ø=4.8
38.5
Ø=30
400
22
Ø=16/18.5
mm
Figure 14 HPP272 Dimensions
Chapter 10 – Technical Data
43
