MI70 indicator
MI70 indicator parts
Figure 1. MI70 indicator parts
1 Charger socket
2
Function key shortcut buttons . The functions change according to what you are doing with the indicator.
3 Arrow buttons:
Move up in a menu
Move down in a menu
Enter a sub-menu
Return to previous menu level
4 Power On/Off button
5 Battery compartment at the back of the indicator
6 2 ports with M12 4-pin female connectors for connecting probes and instruments. The ports are labeled I and II.
To open menus, press an arrow button and then press the shortcut buttons. To activate a function shown above the
shortcut button, press the shortcut button. To navigate in the menus, press the arrow buttons.
Installing and recharging MI70 batteries
Vaisala recommends using the rechargeable battery pack (item code 26755) with GM70, instead of alkaline
batteries.
