Double Mount Installation
#6-32x1 screw
Adapter tab screws
4
4
Included in Wiring Kit (D-PK-3-110-S or D-PK-3-24-S) - 2 kits included
Power/grounding wires
and connector
1
or
110V
24V
PLEASE NOTE: A user will also have to provide a Phillips-head screwdriver, a small flat-blade screwdriver, a single gang box, any equipment needed to install
the gang box, and any additional wiring needed to extend the signal, power, or ground cables. You may also need a 1/4 inch drill, 4 #8x1.5 self-tapping
screws, and 4 wall anchors for those screws if you decide not to attach the clock directly to the gang box.
If any of the items listed in the wiring kit are missing, you may contact Valcom and order a
replacement kit.
