Inputs - System-Side - 2-Wire Digital
V-A2412 or V-A2416
V-A2412B or V-A2416B
Valcom Master Clock
V-D2425B-6 or V-D2440B-6
*V-C6124P and the V-CCU are
ordered as a V-VCU.
Data In
2 Wire Digital
Output to Clocks
24 VDC IN24 volt outputs
+-+-+- +-+-+-
V-A2412 or V-A2416
V-A2412B or V-A2416B
18 19
Black
Black
Yellow
White
White
Orange
V-CCU
V-C6124P
