Valcom V-D11025B User Manual

35
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
P. 540-563-2000
F. 540-362-9800
www.valcom.com
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
P. 540-563-2000
F. 540-362-9800
www.valcom.com
Inputs - Clock-Side - Sync-Wire (V-D110XXB Only)
Dukane
J1-
1
2
3
4
5
6
7 8
9
J2-
1 2
Reset
Minute Pulse
Ground
J1-
1 2 3 4 5 6
7
9
8
Neutral
Reset
110VAC Inter face
J1-
1
2
3
4
5
6
7 8
9
J2-
1 2
Relay
N.O.
COM
Dry Contact Closure
Description:
Midnight Reset or Once a Day Pulse
Description:
Dukane - Applying a 4-10 millisecond pulse on the minute line will increment the clock in one minute.
Applying a 12-50 millisecond pulse on the reset line will bring the clock back to 12:00 a.m.
Midnight Reset or Once a Day Pulse - Applying a pulse for more than two (2) seconds will bring the
clock to the correct time.
