40
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
P. 540-563-2000
F. 540-362-9800
www.valcom.com
The numbers shown on the left are examples. Going down the list and entering every one
of the examples exactly as shown will cause the clock to malfunction or use incorrect data.
Program your clock setting based off of the instructions in the description on the right.
Setting 14 - Loss of Communication Alert Additional Configuration
Allows the user to determine how much time should pass without a
synchronization signal from the master clock before the Loss of Communication
Alert is activated. Press the bottom button to switch between the numerical
options below:
01 - Activates after 5 minutes 05 - Activates after 45 minutes 09 - Activates after 180 minutes
02 - Activates after 10 minutes 06 - Activates after 60 minutes 10 - Activates after 240 minutes
03 - Activates after 15 minutes 07 - Activates after 90 minutes Note: Alert activates after signal
loss for the time limit specified
04 - Activates after 30 minutes 08 - Activates after 120 minutes
Setting 15 - Enable Circuit Board Jumpers
Press the bottom button to switch between “d’ or “E”
“d” disables the jumpers
“E” enables the jumpers
NOTE: Enabling the jumpers overrides Settings 4, 6, and 8. Refer to the section
of this manual labeled “Adjustable Jumper Settings” for information on the
function of each jumper.
Manual Controls (V-D110XXB Only)
14--06
15-- d
To Next Page
