Valeo CC 185T User Manual

ELECTRICAL SYSTEM
3- Controller SBU400/410
SBU 400/410
CLUTCH
SOLENOID
VALVE
D+
TEMPTEMPPAPM ICEPBPM
Alternator
B+
B-
WATER VALVE
M
+ 30
GND
+ 15
Relay board for unique platform application
SBF2XX
Fan LS Fan HS
Condenser
Up to 6 fans
Up to 4 fans
Power source
VDC (M8)
Low / High Pressure / Thermostat freezing N.C. N.C. N.C. N.C. GND GND Duct Temperature Duct Temperature
Fresh Air A Fresh Air B GND Water Valve Water Valve A Water Valve +5Vcc Water Valve B Water Valve Pot. Floor Convector Water Pump (-)
VCC (+15) Convector Alternator Signal (D+) Condenser Radial S2 Fan Radial S1 Fan Clutch Inner Temperature Inner Temperature
Fan LS
Solenoid valve
Clutch
Alternator D+
GND RB
Fan HS Condenser +15 +15 Condenser/Clutch
GND (Relay Board)
In order to check the
output configuration,
see SBF2xx
SC410 Only with Air Renewal and / or Heating
CC 185T - CC 205T - CC 205W
22
