1-Product description - Dimensions TM15
135Ø
16
39.6
±0.6
64.6 83.3
+0.2
14.35
+0.05
-0.15
112
±0.1
215.8( )
120Ø
7/8-14UNF
SUCTION
3/4-16UNF
DISCHARGE
80
142
104
±0.3
104
±0.3
10.3
+0.4
Ø8-
21.5 28.5
D
S
