-12-
1-Product description - Performance TM13
The performance data below were measured under the following conditions:
• Discharge Pressure: Pd = 1.52 MPaG
• Suction Pressure: Ps = 0.18 MPaG
• Subcooling temperature: SC = 5°C
• Super heat temperature: SH = 10°C
Valeo TM13 performance data table (R134a)
TM13
Nc (r/min) 800 1200 1800 2400 3000
Vol. Eff. (%) 58.3 63.0 65.7 63.7 61.1
Capacity (kW) 1.64 2.64 4.13 5.35 6.41
Power (kW) 0.92 1.41 2.22 3.04 3.93
COP 1.78 1.87 1.86 1.76 1.63
Compressor Speed (rpm)
Volumetric Efficiency (%)
Cooling Capacity (kW) / Power (kW) / COP
Valeo TM13 performance data graph (R134a)
