Valeo TM08 User Manual

-13-
1-Product description - Performance TM15
The performance data below were measured under the following conditions:
• Discharge Pressure: Pd = 1.52 MPaG
• Suction Pressure: Ps = 0.18 MPaG
• Subcooling temperature: SC = 5°C
• Super heat temperature: SH = 10°C
Valeo TM15 performance data table (R134a)
TM15
Nc (r/min) 800 1200 1800 2400 3000
Vol. Eff. (%) 57.5 63.3 66.2 64.1 61.4
Capacity (kW) 1.81 2.98 4.65 6.03 7.24
Power (kW) 1.04 1.57 2.50 3.45 4.42
COP 1.73 1.90 1.86 1.75 1.64
Compressor Speed (rpm)
Volumetric Efficiency (%)
Cooling Capacity (kW) / Power (kW) / COP
Valeo TM15 performance data graph (R134a)
