1-Product description - Dimensions TM08
135Ø
16
36.6
±0.6
( )183.3
61.6 67
±0.1
89
±0.1
11
±0.1
120Ø
7/8-14UNF
SUCTION
3/4-16UNF
DISCHARGE
14
°
14
°
5.5
5
80
139.6( )
104
±0.3
104
±0.3
10.3
+0.4
Ø8-
