Section 7 | Electrical
© 2021 – Valeport Ltd
Page | 26
7 Electrical
Power GND and Signal GND are isolated.
7.1 Power uvSVX
9 – 28V DC input (isolated)
Draws approximately 30mA at 12V DC
7.2 Power uvSVXe
9 – 28V DC input (isolated)
Draws approximately 130mA at 12V DC
7.3 Wiring Information
Systems are supplied with a short (50cm) lead for splicing or testing
6 Way Male SubConn (MCIL6M)
PIN
FUNCTION
1
RS232 GND
2
RS232 Tx (Out of sensor) or RS485A
3
RS232 Rx (Into sensor) or RS485B
4
+V
5
Link to Pin 1 for RS485
N/C for RS232
6
Power GND
