Metal Detector VMH3CS – Operation Manual
© 2007 Vallon GmbH, D-72800 Eningen/Germany
Graph A indicates the maximum audio/visual signal upon detection of larger
metal objects.
Graph B indicates the maximum audio/visual signal respectively the vibration
signal upon detection of very small metal striker pins in plastic AP mines
buried in horizontal position.
Graph A Graph B
Fig. 4-3 - area of maximum audio signal below the search head
