APPENDIX F – UXO SEARCH HEAD (OPTIONAL ACCESSORY)
1. General
The large diameter search head which is available as special option provides
for the detection of metallic mines and UXO to large depths below the surface
with reliable and consistent operation. It is delivered completely with a carry
bag.
(1) adjustable arm-rest
(2) control unit with hand grip
(3) telescopic pole protected against twisting
(4) plug-in connection
(5) pluggable search head, round (Option)
(6) battery compartment
(7) connector
4
3
2
6
1
7
5
