Vallon VMH3CS - Appendix F: UXO Search Head

46
Metal Detector VMH3CS – Operation Manual
© 2007 Vallon GmbH, D-72800 Eningen/Germany
LIST OF SPARE PARTS
Pos.
*
Qty. VALLON-No. Description SL
1
*
1
8902290112 Brake of search head
1
2
*
1
2902290026 Pin Vukollan
1
3
*
1
8902290011 Screw, brake
1
4
*
1
8902290026 Fastening screw, brake
1
5 1
2902290114 Search head sealed
2
6 1
2902360103 Carrying bar search head oval
2
7 1
2502360101 Cable search head
2
8 1
8909990621 Ring nut M24x1,5
2
9 1
8902290104 Type foil for mode selector
1
10 1
5110306025 Data output socket/headset 6pole
2
11
*
1
2909990529 Cover 6 pole
1
12 1
8902290003 Protection for "mode selector"
2
13
*
1
5281001011 Collet chuck knob "mode selector"
1
14 1
5100801022 Step switch "mode selector"
2
15 1
5289001013 Cap
1
16
*
1
2909990622 Control panel cplt.
2
17 1
2902290043 Housing
2
18 1
2909990559 Module cplt., firmware vmc1s126_14H or higher
2
19 3
7090187001 Cheese head screw brass M3x20 olive
2
20 3
7110087001 Hexagon nut brass M3 DIN934 olive
2
21 1
2902290116 Back, mounted
2
22 2
7090187002 Cheese head screw brass M4x16 DIN84 olive
2
23 1
2902360102 Carrying bar cplt.
2
24 1
2502360102 Cable detector
2
25 1
9120001002 Dehydrating capsule
2
26
*
1
2909990564 Arm-rest
2
27
*
1
2902290106 Battery cover cplt.
1
28
*
1
9030102009 O-ring D=38x3
1
29
*
2
8909990613 Belt for battery cover
1
30
*
1
2909990530 Non-magnetic test piece
1
* Spare parts recommended by Vallon
SL 1 = Service Level 1 = repair at site / in the field
SL 2 = Service Level 2 = workshop repair
Contents, specifications and availability are subject to change serving the technical
improvement.
