56
Metal Detector VMH3CS – Operation Manual
© 2007 Vallon GmbH, D-72800 Eningen/Germany
The detection area is on the left and right side of the white sign on the top of the stick
probe. That means for checking a hole the stick probe must be turned by 90° to
reach all sides.
2. Technical Data which are different from Appendix C
Dimensions
Telescopic pole with stick probe: min. length: 935 mm 5 mm
max. length: 1278 mm ± 5 mm
Length of stick probe: 445 mm 5 mm
Diameter of stick probe: 40 mm Ø
Length of detection zone: 120 mm
Weights
Detector ready for service
with stick probe: approx. 2.3 kg
Stick probe: approx. 0.58 kg
white marking
detection direction detection direction
