4
1. APPLIANCE DATA
This product uses fuel effect pieces. It makes sense to take
care when handling these articles to ensure that the release
of dust is kept to a minimum.
This appliance does not contain any component
manufactured from asbestos or asbestos related products.
The appliance data label is on a plastic tie below the burner
and is visible when the bottom front cover is removed.
Gas Natural (G20) Propane (G31)*
Inlet Pressure 20mbar 37mbar
Input - Max. (Gross) 6.0kW (20,500Btu/h) 6.1kW (20,800Btu/h)
Input - Min. (Gross) 2.2kW (7500Btu/h) 3.6kW (12280Btu/h)
Output - Max. 3.5kW (11,900Btu/h) 3.6kW (12,280Btu/h)
Output - Min 1.1kW (3750Btu/h) 1.8kW (6140Btu/h)
Burner Test Pressure (Cold) 17.0±0.75mbar (6.8±0.3in
w.g.)
35.6±0.75mbar
(14.3±0.3in w.g.)
Gas Connection 8mm pipe 8mm pipe
Burner Injector Bray Cat. 18 Size 360 Bray Cat. 18 Size 170
Pilot & Atmosphere Sensing
Device
SIT Ref. OP9030 SIT Ref. OPLPG9222
Ignition Piezo Electric. Integral with
Gas Tap
Piezo Electric. Integral with
Gas Tap
Aeration Non-adjustable Non-adjustable
* When converted using Kit 591149
2 GENERAL INSTALLATION REQUIREMENTS
2.1 For the user’s protection, in the United Kingdom
it is the law that all gas appliances are installed by
competent persons in accordance with the current
edition of the Gas Safety (Installation and Use)
Regulations. Failure to install the appliance
correctly could lead to prosecution. The Council
for the Registration of Gas Installers (CORGI)
requires its members to work to recognised
standards.
The Confederation for the Registration of Gas
Installers (CORGI) requires its members to work
to recognised standards.
The installation must be in accordance with these
instructions.
In the United Kingdom the installation must also
be in accordance with:
a) All the relevant parts of local regulations.
b) The current edition of the Building
Regulations issued by the Department of the
Environment and the Welsh Office or the
Building Standards (Scotland)
(Consolidation) Regulations issued by the
Scottish Development Department.
c) All relevant codes of practice.
d) The relevant parts of the current editions of
the following British Standards:-
BS 715
BS 1251
BS 1289 Part 1
BS 1289 Part 2
BS 4543 Part 2
BS 5440 Part 1
BS 5440 Part 2
BS 5871 Part 2
BS 6461 Part 1
BS 6891
BS 8303
In the republic of Ireland the installation must
also conform to the relevant parts of:
a) The current editions of:-
IS 813
ICP3
IS327
All relevant national and local rules in force.
2.2 In the United Kingdom, as supplied, this
appliance can be installed in the following
situations: -
2.2.1 To a fireplace complete with surround and hearth
complying with B.S 1251. The required fireplace,
hearth, debris catchment area and clearance
dimensions are shown in figure 1a.
2.2.2 To a fireplace incorporating a twin walled metal
flue box complying with the constructional
requirements of the current edition of BS 715 and
standing on a non-combustible base. The
dimensions of the flue box must conform to the
opening shown in figure 1b. For flue details see
sections 2.3 & 2.4.
