4
Section 1: Remote Kit (RCK400)
Hardware
The RCK400 kit consists of:
• Receiver
• Valor 10 remote handset*
• Valor 10 handset wall holder
• Battery holder**
• Battery holder cable
See "Hardware Requirements" on page 2 for full
details.
Installing the Receiver
See "Wiring Diagram" on page 3 for details.
1. Disconnect power from the fi replace.
2. Label wires and disconnect from existing Receiver.
See "Wiring Diagram" on page 3 for reference.
These include:
• SPARK (Ignitor) wire
• SW (yellow) wire
• TC (red) wire
• 8-wire bundle to the control valve
• PANEL wire to remote wall switch (if applicable)
• Battery holder cable (if applicable)
• MODULE wire to V-Module (if applicable)
3. Reconnect the wires listed in Step 1.
4. Place Velcro tabs onto the new Receiver, and place
it in the original location. Make sure the RESET but-
ton is facing the direction of easiest access.
Synchronize New Remote Control
Your new Receiver comes with a Valor 10 handset. The
Receiver and the handset must be initially paired be-
fore the fi rst use. (Note that batteries must already be
installed in the wall mounted battery holder)
1. Insert two 1.5 V AAA alkaline batteries in the hand-
set.
2. Locate the RESET button on the front side of the
Receiver.
3. With a thin object, press and hold the Receiver’s
RESET button until you hear one short and one long
beeps. After the second beep, release the reset but-
ton.
4. Within the subsequent 20 seconds, press and hold
the button on the remote handset. will be
displayed on the handset during the pairing se-
quence. You will hear two short beeps confi rming
the pairing is done.
If you hear one long beep, the pairing sequence has
failed or the wiring is incorrect.
This is a one time pairing only and is not required when
changing the batteries of the handset or battery holder.
The remote control system is now ready to use.
If desired, mount the wall holder to the wall, no closer
than 3' to the fi replace. Do not mount the wall holder
above the fi replace.
Proceed to Section 2: V-Module Kit (GV60VM).
Notes
* The handset contains the temperature sensor
and is therefore required to use any thermostatic
functions via the app.
** If there is already an existing battery holder and
cable installed in your fi replace, you may continue
to use it.
Note
This Section applies to 1500I/J, 1600I/J, 1700I/J,
1800J, and 2200J fi replaces only.
All others proceed to Section 2: Power Supply Kit
(GV60VM).
