13
Cleaning your fireplace
WARNING
Risk of severe burns! Surfaces of the
fi replace are very hot during operation.
Ensure fi replace has cooled off before
touching it.
Remove the windows for cleaning
1. Remove all three barrier screens by pulling on
them (They are magnetic, so no tools required).
2. Remove the Hot Glass Warning plate.
3. Locate the window retainer hooks.
Retainer hook
locations (2 per side)
4. Hook the window handle to one of the spring loaded
window levers.
5. Pull the window retainer hooks out and up from the
railing at the top of the side windows.
6. Pull the top of the window
out and up into the gap
between the fi rebox and
outside of the fi replace.
(Note the sills have been
removed from this image
for clarity, but you do not
need to remove them to
pull the window out).
7. Pull the bottom edge out
and down.
8. Repeat steps 4-6 for the
other side window.
