Valor LX Series

8
Gas Shutoff
Gas Line
Receiver (hidden)
Info Card (hidden)
Control valve
Barrier Screens (mesh)
Wndows (glass)
Liner
Fuel Bed - logs,
embers, pebbles
Burner
Platform
Batteries
Pilot
Sill
Parts of your fireplace
Here are the major components of your installed fireplace, with the protective barriers
installed. Your individual fireplace may appear differently depending on your installed
options.
Here are the control components of your installed fireplace, with the barrier screens and
one sill removed. Your individual fireplace may appear differently depending on your
installed options.
LX1 pier
LX2 3-sided
LX2 corner L+R
LX1 pier
LX2 3-sided
LX2 corner L+R
