Valtra T174 User Manual

1
2
3
GUID-B0E43208-3D08-4ED7-826E-AEDB1C2F7BAB
1. I/O test menu
2. ECU view
3. ECU pin view
3.11.4 Fault code view
The fault code view on the A-pillar display shows the active fault codes to the
driver.
You can scroll between the active fault codes by pressing the up and down arrow
buttons in the A-pillar display control panel. The codes are displayed in four parts.
Each part displays one segment of the fault code.
1
2
3
GUID-5A8B0DF1-8B4B-4EFE-99C2-501F23E7C324
1. A segment view of a fault code
2. Currently selected fault code
3. Number of active fault codes
3. Operation
- 166 -

Valtra T174 Specifications

General

Cylinders	6
Max Speed	50 km/h
PTO Speed	540/1000 rpm
Rated Power	174 hp
Engine	AGCO Power
Transmission	PowerShift
Transmission Speeds	30F/30R
Weight	7300 kg
Wheelbase	2, 995 mm
Hydraulic System	Load Sensing
Hydraulic Flow	115 L/min
Cab	Yes
