Valtra T174 User Manual

4.7.5 Maintenance every 1200 hours or yearly
4.7.5.1 Changing the oil in the transmission and hydraulic system
Change the oil in the transmission and hydraulic system periodically.
The transmission and hydraulics share the same oil system.
1. Run the tractor until the oil in the transmission system is warm.
This speeds up the oil drainage and most of the impurities come out with the
oil.
2. Remove the drain plugs under the gearbox and final drives.
1
2
1
GUID-BECEF3F8-4A53-49E7-8871-F12B2A1EE362
1. Final drives drain plugs
2. Gearbox drain plugs
3. Drain the oil into a suitable container.
4. Clean and refit the plugs.
5. Clean the suction strainer.
6. Change the transmission oil filters.
4. Maintenance
- 312 -

Valtra T174 Specifications

General

Cylinders	6
Max Speed	50 km/h
PTO Speed	540/1000 rpm
Rated Power	174 hp
Engine	AGCO Power
Transmission	PowerShift
Transmission Speeds	30F/30R
Weight	7300 kg
Wheelbase	2, 995 mm
Hydraulic System	Load Sensing
Hydraulic Flow	115 L/min
Cab	Yes
