Valtra T174 User Manual

2. Loosen the tie rod locking nut.
1
2
GUID-3597A987-BED1-435C-84DA-90EA697AC8DD
1. Locking nut
2. Adjustment screw
3. Turn the adjustment screw in the right direction.
4. Measure both tie rods.
IMPORTANT: Both tie rods must be of the same length after the adjustment.
5. Tighten the locking nut when the correct distance has been achieved.
6. Check the toe-in.
4.7.5.10 Changing the transmission and hydraulics breather
Change the transmission and hydraulics breather periodically.
IMPORTANT: If the tractor is used continuously in dusty conditions, the breather
must be changed more frequently.
4. Maintenance
- 322 -

Valtra T174 Specifications

General

Cylinders	6
Max Speed	50 km/h
PTO Speed	540/1000 rpm
Rated Power	174 hp
Engine	AGCO Power
Transmission	PowerShift
Transmission Speeds	30F/30R
Weight	7300 kg
Wheelbase	2, 995 mm
Hydraulic System	Load Sensing
Hydraulic Flow	115 L/min
Cab	Yes
