Valtra T174 User Manual

3.21.7.3 Attaching to the mechanical jaw K80
You can attach a trailer to the mechanical jaw K80.
1
2
3
GUID-90C43526-2E09-4B09-AA84-87EB3D63B950
1. Pin
2. Locking pin
3. Locking
1. Remove the locking pin.
2. Pull the pin off and open the locking.
3. Attach the trailer to the jaw.
4. Close the locking and fit the pin.
5. Fit the locking pin.
WARNING: Make sure that the locking pin is fitted correctly.
3. Operation
- 242 -

Valtra T174 Specifications

General

Cylinders	6
Max Speed	50 km/h
PTO Speed	540/1000 rpm
Rated Power	174 hp
Engine	AGCO Power
Transmission	PowerShift
Transmission Speeds	30F/30R
Weight	7300 kg
Wheelbase	2, 995 mm
Hydraulic System	Load Sensing
Hydraulic Flow	115 L/min
Cab	Yes
