Valtra T174 User Manual

1
GUID-6527CD59-5E91-4718-8CDD-58C610BA92A7
1. Lever
1. Pull the lever upwards and turn it to the anticlockwise.
2. Move the jaw to the wanted height.
3. Release the lever.
The locking pins lock the lever to the correct position with the help of the
returning springs.
You can also lift the jaw away from the frame by using the same lever.
3. Operation
- 240 -

Valtra T174 Specifications

General

Cylinders	6
Max Speed	50 km/h
PTO Speed	540/1000 rpm
Rated Power	174 hp
Engine	AGCO Power
Transmission	PowerShift
Transmission Speeds	30F/30R
Weight	7300 kg
Wheelbase	2, 995 mm
Hydraulic System	Load Sensing
Hydraulic Flow	115 L/min
Cab	Yes
