Valtra T174 User Manual

1. Make sure that you connect the towing piece to the correct part on the
tractor.
We recommend that you use a towing bar to tow the tractor horizontally.
1
GUID-4DAA8685-BFDF-49E6-A11B-B7399E5434F4
1. Towing point when the tractor has the front linkage
1
GUID-D44CD272-8B65-4F8C-B89E-D6E2F2446B77
1. Towing point when the tractor does not have the front linkage
When you tow a tractor which has the front linkage, lift the lifting links to the
top position.
At the rear of the tractor, the towing point is the towing device of the tractor.
5. Troubleshooting
- 380 -

Valtra T174 Specifications

General

Cylinders	6
Max Speed	50 km/h
PTO Speed	540/1000 rpm
Rated Power	174 hp
Engine	AGCO Power
Transmission	PowerShift
Transmission Speeds	30F/30R
Weight	7300 kg
Wheelbase	2, 995 mm
Hydraulic System	Load Sensing
Hydraulic Flow	115 L/min
Cab	Yes
