GUID-61A1535A-EAE5-4869-A7E2-359E3574BB25
1. Direction indicator left (yellow)
2. Ignition switch current, max. 10 A (blue)
3. Ground (white)
4. Direction indicator right (green)
5. Parking light right (brown)
6. Parking light left (black)
7. Brake light (red)
Socket at the front end
The power socket at the front end is optional equipment. It can be used for
supplying current for the lights and blinkers of the front implements, for example.
3. Operation
- 99 -
