4.7.4.19 Changing the front PTO housing oil and washing the oil filter
Change the oil of the front power take-off (PTO) housing and wash the oil filter
periodically.
GUID-99F19360-93F2-4051-B353-1E6B36AC0888
1. Breather
2. Protector
3. Front PTO housing fastening screw
4. Oil level hole
5. End plate
6. Filter
7. O-ring
8. Lock ring
1. Drain the oil by opening the two front PTO housing fastening screws at the
bottom of the housing.
2. Remove the protector.
Unscrew the two fastening screws.
3. Release the filter by loosening the lock ring and the end plate.
4. Clean the filter with diesel.
5. Dry the filter with compressed air.
6. Attach the filter and the parts in the contrary order.
Check that the O-ring fits the groove of the end plate.
7. Tighten the two front PTO housing fastening screws at the bottom of the
housing.
4. Maintenance
- 307 -
