6.6 Flange distance for axles
Front, industrial front axle (mm) 1 900
Rear (mm) 1 754
Max rear tyre diameter (mm) 1 999
Min rear rim diameter (inches) 38
Max front tyre diameter (mm) 1 522
Min front rim diameter (inches) 28
Distance between rear mudguards (mm) 960
GUID-1835335E-C423-4BCA-B442-6E5A31AD7AD9
1. Distance between the top of the tyre and the mudguard, 60 mm
2. Distance between the side of the tyre and the mudguard, 40 mm
3. Mudguard
4. Narrowest track
6. Technical specifications
- 385 -
