5. Direct the spray against the air streaming direction.
6. Close the protection plate.
Tighten the knurled-head screw.
7. Lower the air conditioning cooler to the lower position.
Tighten the two fastening screws.
8. Close the engine cover.
4.7.2.4 Checking the oil level in the transmission and hydraulic system
Check the oil level in the transmission and hydraulic system periodically.
Steering, hydraulics and transmission share the same oil system.
GUID-71E25714-1694-4CDA-91F3-ED2400A225E6
1. Transmission oil filling plug
2. Transmission oil level gauge
1. Stop the engine and let it stand for a few minutes.
2. Check the oil level from the oil level gauge.
The oil level must be between minimum and maximum lines.
3. Add oil if necessary.
4. Maintenance
- 272 -
