Fuse Nominal current Description
F4 15A Front waist working lights
F5 15A Upper headlights high beams
F6 15A Upper headlights dipped beams
F7 15A Rear working lights left
F8 15A Rear working lights right
F9 15A Front working lights left
F10 15A Front working lights right
F11 15A Reserve
F12 15A Reserve
F13 15A Radio, subwoofer, coolbox
F14 25A Automatic HVAC fan supply
F15 30A Manual HVAC supply
F16 10A Automatic HVAC control panel
F17 10A Rear window wiper
F18 10A Reserve
F19 10A Mirrors, tachograph
F20 15A Reserve
F21 10A Window heating control
F22 10A Reserve
F23 10A Automatic HVAC control panel
F24 5A Light panel
F25 10A Trailer hitch light
F601 30A Rear window heater
F602 30A Windscreen heater
Relay Description
K1R Upper headlights dipped beams
K2R Upper headlights high beams
K3R Trailer hitch light
K4R Auxiliary relay +15
K5R Auxiliary relay +15
K6R Auxiliary relay +15
K7R Manual HVAC supply
K8R Rear working lights
K9R Front working lights
K10R Reserve
K11R Rear waist working lights
K12R Front waist working lights
K13R Accessory power, radio, coolbox, subwoofer, cab light
K14R Rotary beacon
K601 Rear window heater
K602 Windscreen heater
K25
Rear window wiper intermittent
1)
K26
Rear window wiper brake
1)
K56
Cab light delay
1)
4. Maintenance
- 350 -
