GUID-F64DE483-75FF-4D51-9A29-17BDA57EDD55
1. Light panel on/off button
2. Front working lights
3. Front waist working lights (optional)
4. Rotary beacon light (optional)
5. Rear working lights
6. Automatic operation of the rear working lights
7. Trailer hitch light (optional)
8. Rear waist working lights (optional)
9. Automatic operation of the rear waist working lights (optional)
With the Skyview equipment, the button for the rear working lights also turns on
the side working lights.
1. Turn the light switch to parking lights or headlights position.
The light panel and working lights turn on if the light panel and working lights
were on when the power was previously shut down.
2. Press the light panel on/off button to switch on the light panel.
You can turn on the working lights only after you have switched on the light
panel. When the panel is switched on, the symbol on the on/off button is lit
green. Previously saved working light settings are taken into use.
3. Turn the working lights on and off with the corresponding working light
buttons.
When a working light is turned on, the symbol on the working light button is lit
green. The light is lit green even if the actual working light is not installed.
4. Use the automatic rear working lights with the corresponding working light
buttons.
When the automatic operation is activated, the rear working lights are
switched on automatically when the power shuttle lever is in the reverse
position. With the Skyview equipment, the side working lights works alike.
3. Operation
- 84 -
