PARTS LIST & ILLUSTRATION Section 8 - Pg 03
8.2 Discharge System
PART
KEY DESCRIPTION NUMBER QTY
1 Receiver, Air/Oil Horizontal 047331-001 1
2 Elbow, Swivel 90 Deg. 3/4 Pipe x 3/4 Pipe 048429 1
3 Element, Air/Oil Separator 260017-001 1
4 Valve, Relief, 200 PSI, 1/2" npt 270853 1
5 Tee, Pipe Female Street 1/4 260848-102 1
6 Elbow, 90 Deg. Push On 1/4t x 1/4p 261310 4
7 Adapter, Fill 261975 1
8 Plug, O-ring 1-1/4 261981 1
9 Valve, Service 3/4 261982 2
10 Glass, Sight Oil Level 1-1/2 261984 1
11 Head, Oil Filter 3/4 npt 261990 1
12 Element, Oil Filter 261991 1
13 Valve, 1 1/4 NPT Min. Press. Check 262004 1
14 Switch, Temperature 185 Deg. NO 263704 1
15 Valve, Regulator, 6:1 262047 1
16 Channel, Receiving Mtg. 262251 2
17 Band, Mounting 12" 262252 2
18 Tube, Separator Drain w/ Fitting 262270 1
19 Plug, Pipe Hex 1/2 NPT 263293 1
20 Filter, Orifice, .047 Dia., 1/4 FPT x 1/4 MPT 269788 2
21 Sight Glass, 1/4 FPT 269789 1
22 Valve, Check 1/4 NPT Male 269893 1
23 Tee, 1/4 MPT x 1/4 FPT x 1/4 MJIC 270115 1
24 Valve, Blowdown 1/4 Piston 270807 1
25 Elbow, Pipe Street 1/2 801115-020 1
26 Tee, Reducing 1 x 3/4 x 3/4 802904-033 1
27 Tee, Reducing 1 x 1 x 1/4 802904-041 1
28 Tee, Reducing 1 1/2 x 1/2 x 1 1/2 802906-026 1
29 Elbow, Pipe 90 Deg. Street ½ 801115-020 1
30 Bushing, Reducing 1-1/2 x 1/2 804106-020 1
31 Tee, Pipe galv 1 1/2 804415-060 1
32 Plug, Pipe 1/8 807800-005 1
33 Plug, Pipe 1/2 807800-020 1
34 Nipple, Pipe XS Close 3/4 822212-000 2
35 Nipple, Pipe XS Close 1 1/2 822224-000 1
36 Nipple, Pipe Galv 1 x 3 823116-030 1
37 Nut, Hex Locking 3/8-16 825506-198 6
38 Capscrew, Hex gr5 829106-150 4
39 Capscrew, Hex GR5 3/8-16 x 2 829106-200 2
40 Washer, Flat 3/8" 838206-071 4
41 Elbow, 37FL/90M #06 x 1/4 860206-025 2
42 Nipple, Pipe Hex 1/4 x 1/4 860404-025 1
43 Nipple, Hex Red 1 1/4x 1 861620-100 2
44 Elbow Pipe 90 Deg. Street 1/2 801115-002 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER
