Vanair ADHD Powertech - Inlet Valve Assembly

PARTS LIST & ILLUSTRATION Section 8 - Pg 09
8.5 Inlet Valve Assembly
PART
KEY DESCRIPTION NUMBER QTY
1 Seal, Inlet Valve 265400-001 1
2 Piston, Inlet Valve 265400-002 1
3 Spring, Piston Inlet Valve 265400-003 1
4 Housing, Piston Inlet Valve 265400-004 1
5 Screw, Socket Head M6 x 50 265400-005 2
6 Spring, Inlet Check 265400-006 1
7 Stem, Inlet Valve 265400-007 1
8 Valve, Inlet Check 265400-008 1
9 Screw, Socket Head M6 x 16 265400-009 5
10 O-Ring, Viton 3-1/4 x 3/32 265400-010 1
11 Adapter, Inlet Valve 265400-011 1
NS Tube, Gasket Cement 265400-012 1
NS Tube, Threadlock 265400-013 1
NS Kit, Inlet Repair (Consisting of
Items #1, 3, 5, 6, 10, 12, &13) 265400-014 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER
