PARTS LIST & ILLUSTRATION Section 8 – Pg15

8.8 Above Deck – Hydraulic Drive

PART

KEY DESCRIPTION NUMBER QTY

1 Frame, Compressor Mounting 012745 1

2 Bushing,Taper Bore 1610 1"Bore 049853 1

3 Support,Comp/Hyd Motor 263052 1

4 Decal, Caution O-Ring Fitting 263252 1

5 Motor,Hyd 3.2 Cid 263365 1

5a Motor,Hyd 4.5 Cid 263366 1

Ns Kit, Bolt Package 264911-100 1

6 Hub,Taper Lock E20 Htl Rexnord 408012 2

7 Bushing,Taper Bore 1610 1"Bore 408014 1

8 Element,Coupling We20 408975 1

9 Capscrew, Hex Gr8 3/8-16 X 1 1/4 829406-125 5

10 Capscrew,Hex Gr8 1/2-13 X 1 1/2 829408-150 2

11 Washer, Lock 3/8 838506-094 5

12 Washer, Lock 1/2 838508-125 2

PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER
