PARTS LIST & ILLUSTRATION Section 8 - Pg 05
8.3 Enclosure
PART
KEY DESCRIPTION NUMBER QTY
1 Washer, Flat Nylon ¼ 262704 1
2 Washer, Flat Nylon 5/16 262943 14
3 Screw, Truss HD 5/16 - 18 x ¾ 262945 14
4 Screw, Truss HD 1/4 x 3/4 262953 1
5 Frame, Assembly ADHD-EC 263464 1
6 Panel, End 263469 1
7 Panel, Side R.H. 263471 1
8 Panel, Side L.H. 263472 1
9 Panel, Roof 263473 1
10 Angle, Receiver Tank Mtg. 263484 2
11 Capscrew, Hex HD 1/4 - 20 x ¾ 829104-075 2
12 Capscrew, Hex HD 5/16 - 18 x ¾ 829705-075 6
13 Washer, Flat ¼ 838204-071 5
14 Washer, Flat ½ 838208-112 8
15 Nut, Locking Hex 1/4 – 20 825504-145 3
16 Capscrew, Hex HD 1/2 - 13 x 2 829408-200 4
17 Nut, Locking Hex 1/2 – 13 825508-262 4
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER
