PARTS LIST & ILLUSTRATION Section 8 - Pg 07
8.4 Instrument Panel
PART
KEY DESCRIPTION NUMBER QTY
1 Panel, Gauge 261251 1
2 Decal, Panel Overlay 261349 1
3 Switch, High Temp. Shutdown 260625 1
4 Gauge, Temperature 266331 1
5 Gauge, Pressure 261974 1
6 Gauge, Hour Meter 040035 1
7 Elbow, 1/4T x 1/8P Push-on 261309 1
8 Coupling, Pipe Galv 806230-005 1
NS Relay, NO/NC
• (12V) 260246 1
• (24V) 265182 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER
