PARTS LIST & ILLUSTRATION Section 8 - Pg 11
8.6 Oil Cooling System (Electric) 125 - 185 CFM
PART
KEY DESCRIPTION NUMBER QTY
1 Shroud, Cooler 262109 1
2 Cooler, Oil 125-185 CFM 261992 1
3 Guard, Cooler 125/185 EC 261968 1
4 Fan and Motor Assy
• 12V 264856 1
• 24V 265057 1
5 Elbow, Swivel 90 3/4 FPT x 3/4 MPT 048429 2
6 Screw, Hex Self Thread 1/4 x 3/4 834204-075 4
7 Screw, Ser Washer 5/16-18 x 0.75 829705-075 12
8 Harness, Wire 266607 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER
